2019 Edale Flexographic FL5 Carton Production Press

Maximum Web Width: 20.1" (510mm)

Maximum Print Width : 19.7" (500mm)

Print Repeat: 8" - 24" (203mm - 609mm)

Stock Range - 0.5 - 24 pt

Maximum Run speed: 660 Feet/Minute

Hours: Less than 100

FL5 XL Unwind & Infeed Unit – 60” (150mm) Maximum Roll Diameter

TEKNEK Double-Sided Web Cleaner

MEECH VacClean Contact Web Cleaner for Carton Applications

VETAPHONE Single-Sided Corona Treater (3.0 kW)

(8) FL5 Flexo Print Stations

• UniPrint – Consistently high print reproduction whatever the format size
• AiiR – Motorized print pressure & register control
• Gearless Impression
• Set & Forget Impression – Eliminates impression adjustments between format changes
• On-the-fly setup – Reduces setup times by setting print stations on the run
• Pre-Register – Minimal material wasted during register setting
• Dual Axis Servo Drive – Precision tension control for exceptional registration
• QC Ink System – Color changes in under 90 seconds
• Print to Mark Register – Consistent print quality throughout the job

GEW ARC UV Dryer System

Chilled Impression Roller Assembly

Turn Bar Assembly for 4/4 Printing

Lamination / Foil Modules

• Laminate or foil unwind and driven rewind 23.5” (600mm) diameter
• Moveable cold foil or UV lamination nip roller

EZ REG – Autonomous Print Register Control System

• Automatic register set-up and continuous register monitoring in X & Y direction
• Job data storage and recall
• Ensures consistent quality and control through print run

BST Powerscope 5000 Web Viewing System

Edale FDC 600 Flat Bed Die Cutting System for Carton Production

• Maximum Stroke Length: 28”
• Maximum Cutting Force: 165 tons
• Maximum Diverging Card Delivery: 4 across
• Maximum Performance: 13,000 impressions/hour
• Waste Stripping & Waste Conveyor

FL5 Rewind – 1000mm Rewind Module for Roll to Roll
